AstroBot

Your intelligent space-themed AI assistant — university graduation project.

AstroBot is a full-stack AI chat application built around an n8n workflow that routes messages through Mistral, with a layered set of features on top: image generation, OCR, retrieval-augmented generation (RAG), audio transcription, PDF report generation, image-to-image edits, and a separate admin dashboard.

---

🏗️ Architecture

                       ┌────────────────────────┐
                       │    User browser        │
                       └─────────┬──────────────┘
                                 │
        ┌────────────────────────┼────────────────────────┐
        │                        │                        │
┌───────▼────────┐      ┌────────▼──────────┐    ┌───────▼────────┐
│   Main app     │      │  Admin dashboard  │    │     n8n        │
│  Express :3000 │      │   Express :7040   │    │    :5678       │
│  Public chat   │      │  Admin / stats /  │    │ Mistral cloud  │
└───────┬────────┘      │  user management  │    │ SerpAPI · Think│
        │               └─────────┬─────────┘    └───────┬────────┘
        │                         │                      │
        └───────────┬─────────────┘                      │
                    │                                    │
            ┌───────▼────────┐                  ┌────────▼─────────┐
            │   PostgreSQL   │                  │  HuggingFace     │
            │ (shared)       │                  │ FLUX · BLIP ·    │
            │ users · convs ·│                  │ MiniLM · TrOCR   │
            │ docs · workflows                  └──────────────────┘
            └────────────────┘

Three Docker services on the same private network:

Service	Port	Image	Purpose
astrobot	3000	astrobot:2.0.0	Main user-facing chat app
astrobot-admin	7040	astrobot-admin:1.0.0	Admin dashboard (stats, user mgmt, settings)
n8n	5678	n8n (external)	LLM workflow orchestration

---

✨ Features

Chat experience

• Mistral Medium via n8n with conversation history (last 15 messages)
• Markdown rendering with GitHub-flavored support
• KaTeX for LaTeX math ($E=mc^2$, $$int_0^infty$$)
• highlight.js for code syntax highlighting
• Mermaid diagrams (flowcharts, sequence, ER, etc.)
• Streaming-style word-by-word reveal animation
• Multi-language detection (FR / EN / ES / DE / AR / ZH / JA / KO / RU / EL)
• Theme toggle dark / light
• UI density: comfortable / compact
• 7 personas (default, formal, casual, teacher, dev, poet, scientist)

Multimedia

• 🎨 Image generation via FLUX.1-schnell (HuggingFace, free) with fal-ai fallback
• 📄 PDF report generation via pdfkit (typed responses)
• 🖼️ Image-to-image edit via FLUX dev (style transfer, “make this anime”, …)
• 📎 File / image attachments with drag-and-drop, multi-attach
• 🔊 OCR for images via Tesseract.js (EN / FR)
• 🤖 Visual captioning via BLIP for non-text images
• 🎙 Audio transcription via Groq Whisper (optional, free key)
• 🗣 Text-to-speech for bot replies (Web Speech API, browser-native)

Productivity

• 📚 Notebook mode — pin a PDF as permanent context for a session
• 🔍 Document Q&A (RAG) — chunk + embed via MiniLM, cosine similarity retrieval
• 🎬 YouTube summarizer — fetch transcript + summarize
• 🔁 Workflow chains — saved multi-step prompt sequences
• 🏷️ Tags / folders on sessions with color-coded filters
• 🔎 Search in chat history
• 📤 Export session as PDF / Markdown / JSON
• ✏️ Edit & resend your messages
• 🔄 Regenerate bot responses
• ⏹ Stop generation mid-stream
• 🛡 Profile photo with built-in cropper (rotate / zoom / flip)

Admin dashboard (port 7040)

• 🔐 Admin-only login (regular users get 403)
• 📊 Real-time stats: users / messages / sessions / tokens / images / PDFs / docs
• 📈 Charts (Chart.js): daily activity, user status breakdown
• 👥 User management: list, search, suspend/activate, reset password, delete
• ➕ Admin can create new accounts (regular or admin)
• 📜 Browse any user’s full conversation history grouped by session
• 👤 Self-service settings: profile, password, photo

---

🚀 Quick start

Requirements

• Docker + Docker Compose
• An existing PostgreSQL container on a Docker network (we connect to it as a client)
• An external n8n container with the AstroBot workflow imported
• A HuggingFace API token (free at https://huggingface.co/settings/tokens)
• Optional: Groq API key for audio transcription (free at https://console.groq.com/keys)

1. Clone & configure

git clone https://github.com/tkonate788/astrobot.git
cd astrobot
cp docker/.env.example docker/.env
nano docker/.env       # fill in real values (see below)

The docker/.env file holds all secrets and never gets committed:

Variable	Example	Notes
JWT_SECRET	<random 32+ chars>	Sign user tokens
DB_HOST	postgre_container	Hostname on the docker network
DB_PORT	5432
DB_NAME	astrobot
DB_USER	astrobot_user
DB_PASSWORD	<strong password>
N8N_WEBHOOK	http://n8n:5678/webhook/astrobot	Your n8n entry point
HF_API_KEY	hf_xxx...	HuggingFace token
GROQ_API_KEY	gsk_xxx... (or empty)	Optional, for transcription
ADMIN_EMAIL	admin@example.com	Seed admin login
ADMIN_PASSWORD	<strong password>	Seed admin password

2. Build & run

cd docker
docker compose up -d --build

Both services come up:

• Main app: http://localhost:3000
• Admin dashboard: http://localhost:7040

The admin account is auto-seeded on first run using ADMIN_EMAIL / ADMIN_PASSWORD from docker/.env. Sign in once and start exploring.

3. Verify

# Run the comprehensive test suite (66 tests)
python test_all.py

---

📁 Project layout

astrobot/
├── frontend/              # Static HTML / CSS / JS for the main app
│   ├── index.html         # Landing page with central chat bar
│   ├── chat.html          # Authenticated chat interface
│   ├── login.html
│   ├── register.html
│   ├── style.css
│   └── team/              # Developer photos for the About section
├── backend/
│   ├── server.js          # Express entry
│   ├── db/index.js        # Postgres pool + idempotent migrations
│   ├── middleware/auth.js
│   └── routes/
│       ├── auth.js        # Register / login / profile / avatar
│       ├── chat.js        # Messages + image gen + PDF + history
│       └── features.js    # Documents / RAG / YouTube / img-edit / workflows
├── admin/                 # Separate Express service (port 7040)
│   ├── backend/
│   │   ├── server.js
│   │   └── public/        # Admin dashboard UI (vanilla JS + Chart.js)
│   └── Dockerfile
├── docker/
│   ├── docker-compose.yml
│   ├── Dockerfile         # Main app
│   └── .env.example       # Template for local secrets
├── deploy.py              # SSH + SCP + docker compose deployment
├── test_all.py            # Full integration test suite (66 tests)
└── README.md

---

🧪 Testing

# Set ASTROBOT_HOST / ASTROBOT_ADMIN_EMAIL / ASTROBOT_ADMIN_PASSWORD
# (or place them in .deploy.env), then:
python test_all.py

The suite covers:

• Service health (main + admin)
• Static asset serving with no-cache headers
• Admin auth (correct / wrong / missing token, role check)
• Admin endpoints (/stats, /users, CRUD, suspend/activate, reset-password)
• Main app auth (login, profile, avatar set + clear)
• Chat flow (n8n → Mistral round-trip)
• Tags, sessions, history, exports (PDF/MD/JSON)
• Features endpoints (documents, RAG bind/unbind, workflows CRUD, validation)

---

🛠 Tech stack

Layer	Tech
Frontend	Vanilla HTML / CSS / JS (no framework)
Frontend libs	KaTeX, highlight.js, Mermaid, Cropper.js, Chart.js (admin)
Backend	Node.js 18, Express 4, JWT, bcrypt, Helmet, rate-limit
Storage	PostgreSQL
AI / LLM	Mistral via n8n, HuggingFace (FLUX, BLIP, MiniLM)
Speech	Tesseract.js (OCR), Groq Whisper (optional STT)
Doc parsing	pdf-parse, pdfkit
Container	Docker + Docker Compose, Alpine Node 18

---

🔒 Security notes

• All secrets live in docker/.env (gitignored). No keys committed to the repo.
• JWT-based auth (7-day expiry).
• Helmet headers + per-route rate limiting (auth: 20/15min, chat: 30/min).
• bcrypt password hashing with salt rounds = 12.
• Admin endpoints protected by an is_admin claim in the JWT.
• Static assets served with Cache-Control: no-store to keep updates fresh.
• File uploads capped at 10 MB each, 5 attachments max per message.

---

👥 Team

AstroBot is a university graduation project developed by:

• Tidiane Konaté
• Sidi Mohamed Sall
• Ahmed Essalem
• Saad Ibrahim Houssein

— 2026
